Standard Products- Single Fiber Patch Cables
Click on the Part Number to
Order!
Fiber optic patch cables are assemblies containing a single
fiber. They may be used in a wide variety of sensing, process
control, and spectroscopic applications, where it is necessary
to remotely transmit UV-Vis (180nm-1150nm) and Vis-NIR
(340nm-2500nm) light, with maximum efficiency.
These fiber optic products feature 0.22 numerical aperture fused
silica fibers and PVC monocoil cabling (steel coil with
PVC covering).
End
termination options are SMA, FC, ST, or 0.25"OD ferrules,
except as noted. The operation
temperature range is –40C to +110C. Other numerical aperture
fibers, sheath types, end terminations, and temperature
tolerance levels, are available upon request. |
|
|
PATCH (SINGLE FIBER) CABLES
Connector
code suffixes:
-S = SMA905
connector
-F = FC
connector
-T = ST
connector
-Q = 1/4"OD
ferrule
Use these codes
to designate which connectors you require, for example:
PCU100-1-SF has
an SMA905 connector at one end, and an FC connector at the
other end.
Prices subject to change without
notice.
OPTICAL FIBER- UV/Vis Attenuation Curve
OPTICAL FIBER- Vis/NIR Attenuation Curve
Attenuation
curves do not include losses caused by input/output reflection,
or fiber packing factor. |
|
