Standard Products- Round Round Bundles
Click on the Part Number to
Order!
Round to
round fiber bundles contain multiple individual optical fibers
within a single cable, packed into a round configuration at each
end. They transmit UV-Vis (180nm-1150nm) or Vis-NIR
(340nm-2500nm). Round to round bundles are an ideal solution
where it is necessary to transmit a large diameter beam, while
offering a small bend radius. They may be used in a wide
variety of applications in spectroscopy, process control,
sensing, incident lighting, etc.
Specifications:
- Fiber:
0.22na fused silica. - Sheath: PVC
monocoil (steel coil w/PVC covering)
-
Connectors: SMA, FC, ST, or 1/4"OD ferrule. - Temp.
Tolerance: -40C to +110C. |
|
|
ROUND-ROUND
BUNDLES
|
PART NUMBER click on part # to order |
PRICE
1.0 M |
PLUS
per additional M |
DESCRIPTION |
|
|
190-1100 nm |
|
|
|
|
RRU-122-1 |
$275 |
$75/M
|
1.22 mm diameter |
|
RRU-171-1 |
$370 |
$145/M |
1.71 mm diameter
|
|
RRU-220-1 |
$490 |
$240/M |
2.2 mm diameter |
|
RRU-320-1 |
$830 |
$490/M |
3.2 mm diameter |
|
|
350-2400 nm |
|
|
|
|
RRN-122-1 |
$315 |
$120/M |
1.22 mm diameter |
|
RRN-171-1 |
$445 |
$240/M |
1.71 mm diameter |
|
RRN-220-1 |
$615 |
$385/M |
2.2 mm diameter |
|
RRN-320-1 |
$1040 |
$785/M |
3.2 mm diameter |
|
Prices subject
to change without notice.
Connector code
suffixes:
-S = SMA905 connector
-F = FC connector
-T = ST connector
-Q = 1/4"OD ferrule
Use these codes to designate which connectors you require, for
example:
RRU-122-1-SQ has an SMA905 connector at one end, and a 1/4"OD
ferrule at the other end. OPTICAL FIBER- UV/Vis Attenuation Curve
OPTICAL FIBER- Vis/NIR Attenuation Curve
Attenuation
curves do not include losses caused by input/output reflection,
or fiber packing factor. |
|
